Innovative CathHELIX Technology
™
The CathHELIX System is designed to deliver the functionality of an annuloplasty procedure, with the ease-of-use of a transcatheter procedure.
CathHELIX Components
Unique nitinol CathHELIX ring
has innovative micro anchors to provide automatic and durable fixation
Commisure curve
Raised portion of ventricular ring compresses along anterior portion
Self-fixating anchors over posterior section
Rings compress valve tissue in sub-annular and supra-annular groove
Stent-like frame over intermediate ring cover provides anchor support
CathHelix Catheter System
S2 3D catheter – circumnavigates the mitral annulus and supports implant delivery
S1 guide catheter – facilitates transeptal placement of system
Expands and seats at the ostium of the coronary sinus
MARS (Mitral Annular Reduction System)
Anchor balloon and ostial dock
Retractable portion with lumen for temporary downsizing
Distal balloon anchor
